There are currently two versions for the V40 mainboard: The standard version with W-LAN and the full version with additional Bluetooth 4.0, GPS, POE Plug-in and OTG port. This is faytech’s most cost effective yet powerful Quadcore solution for Android based platforms.
Powered by the powerful Embedded V40 Mainboard, faytech’s Embedded Touch PCs are the best solutions to industrial automation, device control and digital signage. A powerful Allwinner® V40 QuadCore CPU, Mali400MP2 graphics chipset, various connectors, e.g. USB, serial, network, TTL/UART, Mini-PCIe, HDMI, VGA, GPIO, LVDS and extended DC-In, all that makes the Embedded series perfect choice for reliable solutions.
The Embedded PCs are equipped with 1G DDR3 RAM, 8G flash memory and includes a SATA connector as well as SD card slot for further storage expansion. As for network connection, the device is already integrated with Wifi, over Mini PCIe the device can be upgraded to 3G+GPS using the existing SIM card slot.
The touch features capacitive 10-finger multitouch panels, Anti-glare chemical etched treatment and optionally bonded to the LED backlighting panels, backed by faytech’s warranty for pixel accuracy (A + quality).
The design of the Embedded Touch PCs follows the application: flat easy to integrate IP65 front and stable rear housing with either VESA 75 or VESA 100 mounting for fixing / integration.• Allwinner® V40 Cortex™ A7 QuadCore 1GHz Processor• 1 GB DDR3 RAM & 8 GB EMMC FLASH• Android 6.0• Optional Bluetooth & GPS via Mini PCIe 3G and 4G support• 10-Finger-Multi Touch Capacitive Touch Panel• Patented IP65 front with silicon seal• VESA 100 Mounting• 2 year guarantee
