15.6″ Interactive Mirror

$1,399.31



Product Details

Product Name: 15.6″ Interactive Mirror (V40)



  • Allwinner® V40 Cortex A7 QuadCore Processor
  • 1GB RAM Memory & 8GB FLASH Storage
  • Pre-installed Android 6 operating system
  • Full HD Resolution – 1920 × 1080
  • Mirrored screen with Optically bonded Touch Panel to LCD Panel
  • 10-Finger-Multi Touch Capacitive Touch Panel with Mirror Effect
  • Backlight- and LED-strip brightness control software
  • Integrated W-LAN and Bluetooth 4.0 module
  • Comprehensive IP65 protection
  • 2 year guarantee (24/7 usage)

Available on backorder

SKU: FT156V40MIRROR Category:

The interactive mirrors from Faytech are the ideal choice for bathrooms, whether they are public or private, in hotels, malls, aircraft, or any other setting that calls for a smart mirror! The display is powered by the robust Embedded V40 mainboard, which comes pre-installed with the Android operating system and software to regulate the brightness of the LED strip and backlight.

Utilizing Bluetooth 4.0 or WiFi, it may be quickly connected to your smart device, such as a smartphone. It is also possible to use it as a solo Android display. The touch mirror has one-sided mirror treatment, 10-finger capacitive multitouch panels, and an optically bonded touch panel to LCD screen. It is covered by a Faytech warranty for pixel accuracy (A+ quality). There are customization choices available, such as front LED strip customization, high brightness customization, and more!

Weight 17.636 lbs
Dimensions 25.98 × 19.88 × 0.728 in

Product Specifications

Stock Keeping Unit FT156V40MIRROR
NAV number 3030501648
European model code 1010501560
EAN number 6920734016815

IP Classification

IP65

Computer System

Central Processing Unit Quad Core Allwinner® V40
Motherboard Chipset ARM Cortex-A7
Graphics Processing Units ARM® Mali-400 Mp2, Complies with Open Graphics Library for Embedded System 2.0/1.1
Audio Chip Embedded High-Fidelity 100 decibel Audio Codec Dual analog microphone, 2×6 Watts amplifier
Random Access Memory (RAM) 1GB Double Data Rate (DDR) 3
Flash Memory 8GigaBit Embedded Multi-Media Card Flash
Network Driver 10 | 100 | 1000Mega bit Network; Wireless LAN
Supported Operating System Android 6.0 / 4.4
Preinstalled Operating System Android 6.0 / 4.4

Liquid Crystal Display

Display size 15.6″ / 39.6 cm
Viewable screen area 34.42 cm x 19.36 cm (13.55 in x 7.622 in)
Image Aspect-ratio 16:9
Native resolution 1920*1080px
Maximum resolution 1920*1080px
Screen Luminance 1000 candela/m²
Color Contrast 800:1
Average responsiveness Rise time/Fall time 15/15 ms
Viewing angle (horizontal to vertical) 170 | 170 °
Screen Backlighting LED
Backlighting lifespan 30 000 H

Touch Screen

Touch type PCAP Multi-touch (10 point)
Touch port Universal Serial Bus
Lifespan Unlimited
Screen hardness Mohs 7H

Mechanical/Operation

Temperature range 14°F to 140°F (-10°C to 60°C)
Supported moisture 10 % ~ 90 % Relative Humidity
Weight (net) 5.65 kg / 12.456 lb
Weight (gross, including cartonage) 8.00 kg / 17.636 lb
Enclosure Mirrored Front, Aluminum Housing
Housing sizes 660.0 mm x 505.0 mm x 18.5 mm (25.98 in x 19.88 in x 0.728 in)
Mounting Keyhole suspension mount (36 x 52)

Power Specifications

Source ACDC Switching Power Adapter 100~240V; DC-Out 12 V
Power input 8-18 V
Energy usage 15 W
Idling current 1 W

External Connectors

1x 8-18V DC-In (screwable)

Included in the delivery

Power Source (cf. Power Specifications section)
Installation Guide



Documents & Drivers

Acrobat Reader External website
3D design Download 3D design
Data-sheet Download Data-sheet
Short User Manual Short User Manual
Drivers for capacitive touch (Linux excluded) Capacitive Touch Drivers (RAR) | Rar conversion to ZIP online
Drivers for Linux Download Capacitive Touch Drivers Linux (deb)
Driver for WiFi WiFi driver (RAR) | Rar conversion to ZIP online
