15.6″ Interactive Mirror

$895.00

faytech’s interactive mirrors are the perfect solution for public or private bathrooms, in hotels, shopping malls, airplanes or any other field that requires a smart mirror! The device is powered by the powerful Embedded V40 mainboard with pre-installed Android system and software.

It can be easily connected to your smart device, e.g. smartphone, using bluetooth 4.0 or WiFi. Of course it can also be used as a standalone android device.

The touch features capacitive 10-finger multitouch panels, one-sided mirror treatment and Optically bonded touch panel to LCD panel, backed by faytech’s warranty for pixel accuracy (A + quality).

Customization options are available, these include but are not limited to LED strips on front, High brightness, and more!

  • Allwinner® V40 Cortex A7 QuadCore Processor
  • 1GB RAM Memory & 8GB FLASH Storage
  • Pre-installed Android 6 operating system
  • Full HD Resolution – 1920 × 1080
  • Mirrored screen with Optically bonded Touch Panel to LCD Panel
  • 10-Finger-Multi Touch Capacitive Touch Panel with Mirror Effect
  • Backlight- and LED-strip brightness control software
  • Integrated W-LAN and Bluetooth 4.0 module
  • Comprehensive IP65 protection
  • 2 year guarantee (24/7 usage)
SKU: FT156V40MIRROR Category:

faytech’s interactive mirrors are the perfect solution for public or private bathrooms, in hotels, shopping malls, airplanes or any other field that requires a smart mirror! The device is powered by the powerful Embedded V40 mainboard with pre-installed Android system and software to control the backlight- and LED-strip brightness.

It can be easily connected to your smart device, e.g. smartphone, using bluetooth 4.0 or WiFi. Of course it can also be used as a standalone android device. The touch features capacitive 10-finger multitouch panels, one-sided mirror treatment and Optically bonded touch panel to LCD panel, backed by faytech’s warranty for pixel accuracy (A + quality). Customization options are available, these include but are not limited to LED strips on front, High brightness, and more!

Weight 17.636 lbs

Product Details

Model number FT156V40MIRROR
Global article code 3030501648
European article code 1010501560
EAN number 6920734016815

IP Rating

IP 65

LCD Panel

Screen diagonal 15.6″ / 39.6 cm
Display active screen size 34.42 cm x 19.36 cm (13.55 in x 7.622 in)
Aspect ratio 16:9
Physical resolution 1920×1080 px
Maximum showable resolution 1920×1080 px
Brightness 1000 (cd/m²)
Contrast 800:1
Typical reaction time Tr/ Tf 15/15 (ms)
Visual angle horizontal/vertical 170/170 (°)
Backlight LED
Backlight lifetime 30000 (hours)

Touch Panel

Touch technology Projected Capacitive 10-point Multitouch with mirror effect
Touch lifetime Unlimited
Surface hardness 7H

Operation/Mechanical

Operating temperature -10 °C ~ +60 °C (14 °F ~ 140 °F)
Humidity range 10% – 90% RH
Net weight 5.65 kg / 12.456 lb
Gross weight (incl. cartonage) 8.00 kg / 17.636 lb
Housing material Mirrored Front, Aluminum Housing
Housing sizes 660.0 mm x 505.0 mm x 18.5 mm (25.98 in x 19.88 in x 0.728 in)

Power

Power supply 100-240V ACDC active switching; 12V DC-Out
Working power 8-18 V
Power consumption 15 W
Standby power 1 W

External Connectors

Video 1x HDMI 1.3 (incl. HDCP)
1x DVI-D
1x VGA
Audio Integrated HI-FI 100dB Audio Codec Dual analog mic, 2x6W amplifier
Touch Connectors 1x USB
Other Connectors 1x 12V DC-In (screwable)

Included in the delivery

Power Supply (see Power section)
Short Installation Manual

IP Rating

IP 65

PC System

CPU Allwinner® V40 QuadCore
Chipset Cortex A7
GPU Graphics ARM® Mali400 Mp2 Complies with OpenGL ES 2.0/1.1
Audio Integrated HI-FI 100dB Audio Codec Dual analog mic, 2x6W amplifier
Memory 1GB DDR3
Storage 8GB EMMC Flash
Network 10M/100M/1000M Network; W-LAN
Driver Support Windows 10 + Linux Ubuntu
Preinstalled OS

LCD Panel

Screen diagonal 15.6″ / 39.6 cm
Display active screen size 34.42 cm x 19.36 cm (13.55 in x 7.622 in)
Aspect ratio 16:9
Physical resolution 1920×1080 px
Maximum showable resolution 1920×1080 px
Brightness 1000 (cd/m²)
Contrast 800:1
Typical reaction time Tr/ Tf 15/15 (ms)
Visual angle horizontal/vertical 170/170 (°)
Backlight LED
Backlight lifetime 30000 (hours)

Touch Panel

Touch technology Projected Capacitive 10-point Multitouch with mirror effect
Touch lifetime Unlimited
Surface hardness 7H

Operation/Mechanical

Operating temperature -10 °C ~ +60 °C (14 °F ~ 140 °F)
Humidity range 10% – 90% RH
Net weight 5.65 kg / 12.456 lb
Gross weight (incl. cartonage) 8.00 kg / 17.636 lb
Housing material Mirrored Front, Aluminum Housing
Housing sizes 660.0 mm x 505.0 mm x 18.5 mm (25.98 in x 19.88 in x 0.728 in)

Power

Power supply 100-240V ACDC active switching; 12V DC-Out
Working power 8-18 V
Power consumption 15 W
Standby power 1 W

Internal Connectors

External Connectors

1x 8-18V DC-In (screwable)

Expansion Slots

Included in the delivery

Power Supply (see Power section)
Short Installation Manual

Downloads

Acrobat Reader for PDFs Download from external page
3D model Download 3D model (PDF)
Datasheet Download Datasheet (PDF)
Short-Manual Download Short-Manual (PDF)
Capacitive touch drivers (w/o Linux) Download CTD (RAR) | Online Rar to ZIP
Capacitive touch drivers Linux Download CTDL (deb)
WiFi driver Download WiFi (RAR) | Online Rar to ZIP
