15″ Capacitive Touch PC (i5-7300U)

$2,187.97

Product Details

Product Name: 15″ Capacitive Touch PC (i5-7300U)

  • Intel® Core™ i5-7300U CPU
  • 8GB RAM memory, 128GB Industrial SSD
  • Supports Windows 10 & Linux (32Bit, 64Bit)
  • Anti-glare surface treatment (chemical etching)
  • 10-Finger-Multi Touch Capacitive Touch Panel
  • 1.1mm cover glass with 7H surface hardness
  • Optically bonded Touch Panel to LCD Panel
  • Patented IP65 front with silicon seal
  • Integrated W-LAN
  • 2 year guarantee

Optional: i3-7100U / i7-7600U Core CPU

Available on backorder

SKU: FT15I5CAPOB Categories: ,

Faytech NA 15″ Capacitive Touch PC (i5-7300U, OB) are manufactured with fanless technology, a high standard of reliability and excellent craftsmanship. The Faytech touch screen products separate themselves from the competition in terms of quality and functionality.

Faytech NA 15″ Capacitive Touch PC series is the best choice for commercial and industrial use that requires maximizing available space. These small capacitive touch PC units have stylish flat edge-to-edge glass faces. They come with IP65-rated dust and waterproof front panels to ensure that the units will continue to function in a variety of environments.

The small 15″ Faytech capacitive PCs can be used as point of sale interfaces, industrial controls, as kiosks, automation system controls, and even digital signage in stores, classrooms, hospitality, entertainment and dining industries.



Potential Use Case Scenarios



In-kiosk systems, Point of Sales (POS) systems in the retail, hospitality, entertainment, or restaurant industries, panel control in an industrial setting, digital signage in classrooms or stores, and industries like manufacturing and logistics are just a few applications where Faytech 15" Capacitive touch PCs (i5-7300U) stand out as the touch display and touch PC are already integrated into one device.

The VESA stands that come with Faytech Capacitive Touch PCs allow you to place them on a wall or incorporate them into another surface or machine. These devices are the best option for usage in industrial settings where the workspace needs to be maximized thanks to their versatility. These displays' use of touch technology eliminates the need for a keyboard or mouse, which can assist prevent a workplace from becoming too cluttered. All things considered, these tools may greatly increase the safety and space of your workspace, whether it is a production area or a control center.



Modern 3D TVs, mobile phones, consoles, cash registers, and interactive kiosks all have capacitive touch PCs. Faytech Capacitive touch PCs are an excellent choice for a wide range of commercial and industrial applications since the capacitive touch technology used in such displays is significantly more engaging and user-friendly than the resistive one.

Touch screen PCs are becoming more and more common in a wide range of business settings, including ATMs, CBLs (computer-based learning), and the transportation sector (airports, railway stations, metro stations, bus stops). In restaurants utilizing a Touch PC, such as fast-food chains, consumers may use the touch screen to order and pay, without having to ask a server for help. Touch PCs are easier for learners to use in CBL since they don't have a keyboard. Additionally, it is simpler to make sure that students are paying attention to the display.



Numerous applications for Faytech Capacitive Touch PCs exist, including the following:

Our Touch PCs may be utilized as POS systems in pubs, restaurants, and other retail locations, making it simpler for the staff member to process orders utilizing touch screens. In a similar line, Faytech Capacitive Touch PCs would be quite beneficial for retail establishments since they can inform customers and make it easier for them to browse your goods. For example, a Capacitive Touch PC might be used to inform clients about the goods that are presently in stock, any current promotions, and much more.

Our capacitive touch PCs may be utilized as industrial control interfaces to automate a manufacturing process and manage a production line.

Because they considerably improve connection with consumers, Faytech Capacitive Touch PCs are particularly advantageous in kiosk systems. They may be used to inform, educate, and even sell goods to your audience.

Using Faytech Touch Screen PCs may assist you with tracking and after-sale services in the logistics and transportation sectors. These Touch PCs may also be utilized in the transportation industry to display purchasing alternatives and make it simpler for customers to purchase tickets.

In any home or business automation system, Faytech Capacitive Touch Screen PCs would be a terrific addition and could be utilized as an interactive interface. Similar to this, employing a Touch PC may make answering guest service requests much easier at hotels and hostels.

However, there are other potential use cases as well. Capacitive Touch PCs are also frequently found in workplaces, labs, and as digital signage controllers. Whatever business you are in, these PCs are a low-cost, tried-and-true way to boost your sales and lower your operational expenses.



The accessibility and low danger of error with Faytech Touch PCs are two of its primary benefits. Because they require practically no training to use, these devices are very frequently seen in commercial and office settings. Such displays will eventually show to be remarkably cost-effective for your business.

Owing to the premium materials used in their manufacturing, our Capacitive Touch PCs are also renowned for their sturdiness. Our touch screen computers have a 7H surface hardness cover glass, a tough aluminum casing, and are designed to run continuously. These characteristics make Faytech Touch PCs suitable for usage in harsh locations including factories and outdoor applications. Additionally, the IP65 front panel design of Faytech Capacitive Touch PCs makes them resistant to dust, rain, oil, and other liquids and filth. This makes it possible to use these PCs in establishments like restaurants, bars, hospitals, and busy public areas. Additionally, the package contains sturdy VESA 100 or 75 bolts, enabling you to install your device safely without worrying that it will tumble to the ground.

Faytech touch PCs will help you save crucial space in your business even more than our touch displays. These displays offer a complete package because the touch monitor and PC are integrated into one device. As previously stated, a mouse or keyboard are not necessary while using a touch PC. Overall, switching to touch PCs from non-touch devices will free up more room for equipment or personnel. Faytech Capacitive Touch PCs are ideally suited for usage on the production floor because of this characteristic.



The following common versions of the capacitive touch PCs are offered by Faytech NA:

  • Intel® Pentium® N4200 QuadCore processor, 2.50 GHz core speed
  • Intel® Core™ i5-7300U DualCore Processor, 2.60 GHz core speed

The N4200 Processor may give power-efficient performance and is a fantastic solution for simple applications, whereas the i5-7300U Processor is significantly more powerful and would be appropriate for use case scenarios where high performance is required.



Do not hesitate to get in touch with our specialists right away if you're thinking about introducing Capacitive Touch PCs to your business. We are the market leader for capacitive touch screen devices on a worldwide scale. It would be our pleasure to assess your use case scenarios and offer you recommendations for the best touch device to utilize with your particular applications.

Weight 15 lbs
Dimensions 14.13 × 11.45 × 2.795 in

Product Specifications

Stock Keeping Unit FT15I5CAPOB
NAV number 3030509534
European model code 1010502293
EAN number 6920734000126

IP Classification

Front IP 65 / Back IP40

Computer System

Central Processing Unit Kaby Lake U Intel® Core™ i5-7300U
Graphics Processing Units High Definition Graphics Intel®
Audio Chip Audio CODEC Realtek ALC3251
Random Access Memory (RAM) 8GB non-parity Double Data Rate (DDR) 4 (maximum 16Go)
Swappable Storage Industrial Faytech SSD 128GB
Network Driver M.2 E-key Wi-Fi card; x2 Realtek PCIe GBE LAN 8111G Network Driver 1000Mbps
Supported Operating System Linux Ubuntu + Windows 10
Preinstalled Operating System Linux Ubuntu

Liquid Crystal Display

Display size 15″ / 38.1 cm
Viewable screen area 30.40 cm x 22.80 cm (11.96 in x 8.976 in)
Image Aspect-ratio 4:3
Native resolution 1024*768 pixels
Maximum resolution 1920*1200 pixels
Screen Brightness 300 cd/m²
Color Contrast 700:1
Average responsiveness Rise time/Fall time 8/12 ms
Viewing angle (horizontal to vertical) 160 | 160 °
Screen Backlighting LED
Backlighting lifespan 30,000 H

Touch Screen

Touch type PCAP Multi-touch (10 point)
Lifespan Unlimited
Screen hardness Mohs 7H
Surface coating Anti-reflective (industrial etching)
Glass reinforcement Chemically Reinforced

Mechanical/Operation

Temperature range 14°F to 140°F (-10°C to 60°C)
Supported moisture 10 % ~ 90 % Relative Humidity
Weight (net) 3.40 kg / 7.4957 lb
Weight (gross, including cartonage) 5.30 kg / 11.684 lb
Enclosure Aluminium IPC rear case, rubber frame
Housing sizes 359.0mm x 291.0mm x 71.0mm (14.13in x 11.45in x 2.795in)
Clamps supported Yes
Clamps cut-out (LXH) 335.0mm x 274.0mm (13.18in x 10.78in)
Number of clamps necessary 6
Mounts VESA 100×100

Power Specifications

Power light Green LED
Source ACDC Switching Power Adapter 100~240V; DC-Out 12 V
Power input 12 V
Energy usage 30 W
Idling current 1 W

Internal Computer Connectors

1x SODIMM, maximum 16 Go, DDR4 1866/2133 non-parity, Single channel RAM
x3 COM Rs-232/485 Bios
x2 Complete LCD Backlighting Interface/LCD voltage tester
x1 5V/12V USB to IDE Serial ATA power connector
x1 12V DC connector plug (2-pole)
x1 4-pin Serial ATA power cable adapter
x1 S/PDIF header pin-outs
x1 8-bit Mid-Range Digital IO
x1 Header Mic-In / Line out
x1 USB Front Panel header
x1 SATA 6gb s
x1 Mobile Industry Processor Interface (MIPI) Camera Serial Interface (CSI)
1x Box header for LVDS
2x Box header for USB 3.0

External Computer Connectors

x1 12 Volt DC-In Power Supply (screwable)
x1 RP SMA male WLAN antenna connector
x4 USB 3.0 port
x1 High-Definition Multimedia Interface (HDMI) port
x1 DisplayPort
x1 EAR-Out and MIC-In
x1 10-PIN DIO as RJ50
x1 COM – switchable RS 232/422/485; option 5V/12V/RI (DSUB9, COM1)
x1 COM – RS 232; RX/TX (DSUB9, COM2)
x2 COM – RS 232 and 485; RX/TX and A+/B- (RJ12, COM3&4)
x2 Ethernet 10/100/1000Mbps RJ45 Ports
x1 2.5″ module slot, including swappable SSD

Expansion Ports

x1 full size mSerial ATA Solid-State Drive (SSD)
x1 M.2 Wifi E-Key Socket
x1 SATA-IO connector
x1 External PCIe x1 Straddle-mount connector

Included in the package

Power Source (cf. Power Specifications section)
Installation Guide
Computer Stand
Antenna WLAN RP-SMA female

Documents & Drivers

Acrobat Reader External website
3D design Download 3D design
Data-sheet Download Data-sheet
Short User Manual Short User Manual
Drivers for capacitive touch (Linux excluded) Capacitive Touch Drivers (RAR) | Rar conversion to ZIP online
Linux Touch Drivers Capacitive Touch Drivers for Linux (deb)
Driver for WiFi WiFi driver (RAR) | Rar conversion to ZIP online
Kaby Lake U Drivers for Windows Kaby Lake U Drivers for Windows (RAR) | Rar conversion to ZIP online
